RME MADIface XT USB 3.0 Audio Interface
Experience unparalleled audio performance with the RME MADIface XT, the world's pioneering USB3 audio interface. Despite its compact size, it delivers access to hundreds of audio channels, making it the ultimate portable solution. Seamlessly compatible with USB 2.0 for versatile connectivity (with computer I/O capped at 70 channels), it also boasts a unique PCI Express port for lightning-fast interfacing via External PCI Express cards or Thunderbolt adapters, ensuring maximum channel count and minimal latency.
Crafted for both live and studio environments, the MADIface XT features two premium mic/line preamps, two balanced line outputs, and a stereo phones output for comprehensive I/O capabilities. Take control with full stand-alone operation and remote control over MADI, alongside TotalMix FX for limitless mixing, routing, and processing possibilities.
For added convenience, consider enhancing your setup with RME's Advanced Remote Control (optional). From seamless digital audio transfer from MADI-equipped devices to simple analog connectivity for analog sources, the MADIface XT streamlines installation with Plug and Play technology. With its array of unique features and intuitive configuration options, the MADIface XT stands as the pinnacle of digital audio interfaces.
Main Features:
- Full standalone operation, no computer required
- DURec-integrated digital recorder allows you to record directly to USB memory devices
- All channels (20 inputs and 20 outputs) can be individually chosen for recording and playback
- CV/gate low-latency voltage control for automating synthesizers, mixing consoles, and effects
- SteadyClock FS reference-class digital clocking
- USB out for ARC USB remote control (available separately)
- Compatible with TotalMix FX for iPad
- DIGICheck turns the interface into a highly versatile front-end for audio measurements and software development
- Class-compliant mode for Linux environments and compatibility with iPads and iPhones (separately available connection kits may be needed)
- Crisp high-resolution color display shows metering for all input and output channels
Eight Analog Inputs
- Two XLR-1/4" combo mic/line preamps with phantom power and up to 75 dB of gain, plenty even for low-output dynamic mics such as the Shure SM7B
- Two 1/4" TRS inputs for balanced line-level sources or unbalanced Hi-Z instruments
- Input sensitivity for line/Hi-Z inputs switchable to 19 or 13 dBu
- Four rear-panel balanced 1/4" TRS line-level inputs with up to 12 dB of gain, perfect for patching in synths or outboard gear
- All analog inputs are digitally controlled
Eight Analog Outputs
- Six balanced 1/4" TRS line outputs with high dynamic range (115 dBA) and three selectable output levels (+19, +13, or +4 dBu)
- High-power 1/4" stereo headphone output
Digital I/O
- 8-channel ADAT I/O via TOSLINK optical ports
- 2-channel AES3 I/O via breakout cable
- 2-channel S/PDIF I/O via breakout cable
- USB Type-B host connection for Mac/Windows/Linux supports USB 2.0 and 3.0 standards
Extra Connections
- DIN 5-pin MIDI I/O for connecting keyboard controllers, arranger workstations, and synthesizers
- BNC wordclock jack can be assigned as an input or output
- Barrel input for included power adapter
