Details
The newest fixture in ADJ’s popular Vizi Series, the Vizi Beam RXONE, is a compact and quick moving head with a potent Osram® Sirius HRI 1R discharge long life lamp (6,000 hrs.) that produces a super sharp 3-degree beam of light that travels up to 100 meters. This 16-bit, nimble mover also includes a frost filter to give the beam a wash effect of 21-degrees making this fixture very useful for a variety of portable and permanent applications.
Under the hood the Vizi Beam RXONE boasts a 16-facet prism to break apart the solid beam into 16 mini beams, 14 color + white and 15 static, fixed GOBOs. The RXONE has 2 DMX modes (15 or 17 channel mode), 3-pin DMX In/Out, PowerCon In/Out plus a low power consumption of only 199W at max power.
Specifications
FEATURES:
• LED DMX 4-Button menu system
• 3-degree beam angle
• GOBO Shake effect
• Independent gobo and color wheels
• Pan/Tilt Invert
• Built-In Pan/Tilt Macros
• Shutter: Pulse effect; random strobe slow to fast
• Strobe effect
• Frost Filter (21-degree beam angle)
• Stepper motors with micro stepping
• UC IR Compatible (Not Included) & Airstream IR APP Compatible
SPECIFICATIONS:
• Lamp: Osram® Sirius HRI 1R discharge, 9,000˚K – 6,000 hr. long life
• LUX: 76300 @ 10M, 33900 @ 15M
• 2 DMX Channel Modes: 15 or 17 DMX channels
• 14 colors + white and Split Colors
• 15 static, fixed GOBOs + spot
• 16-facet Prism with macros
• Pan: 540-degree
• Tilt: 270-degree
• 16-Bit Pan/Tilt Positioning
• Auto X-Y repositioning
• 3-pin XLR In/Out
• Power Consumption: 199W
• PowerCon In/Out
• Electronic Dimming: 0% - 100%
• Strobe Rate: 0.3-12HZ
• Multi-voltage Operation: 100-240V, 50Hz/60Hz
• Daisy Chain up to 8 fixtures max (@ 120V); 16 fixtures max (@ 230V)
• Dimensions (LxWxH): 225 x 279 x 387mm / 9” x 11” x 15.25”
• Weight: 9.2kg. / 20 lbs.
• ETL Approved
