Mogami W2932 Multipair 8 Channel Bulk cable is sold by the foot with minimum of 5 feet and increments of 5 Feet
Mogami multicore cables are designed for the highest level of audio performance and feature superb electrical and mechanical characteristics while remaining compact, superflexible and easy to use.
Features:
- Individually twisted shielded pairs
- XLPE (Cross Linked Polyethylene) insulation provides superb electrical characteristics and will not melt or shrink back during soldering.
- Rugged and flexible construction that is easy to handle, even at temperatures down to -20°C (-4°F).
- Easy cable identification system:
- Channel numbers are printed and underlined on each core jacket to ensure correct identification, regardless of which end is stripped.
- Outer jackets of each pair are colour coded by standard resistor colour code, allowing quick identification of conductor pairs.
- Inner conductors are also colour coded based on the international standard resistor colour code. Each pair is colour coded by jacket and conductor colour combination.
- Each channel has a drain wire and served (spiral) bare copper shield. The drain wire simplify termination and can be crimped by the same size contact as the inner conductor pair.
- CL2 rated version available. Conductor size of CL2 rated version is thicker #25AWG so that it is also recommended for rugged application and firm and easier crimp terminal connector wiring as well as NEC fire regulation requirement.
Orders accepted in 5 feet increments ONLY
(example 5,10,15, 20, 25, 30 etc.).
